Inspired by you. Designed for your patients
The HAMILTON-HF90 is an all-in-one solution for high flow oxygen therapy, providing caregivers with the tools and flexibility needed to tailor treatment to each patient’s unique needs.
A simple solution to enhance patient comfort and enable patient mobility.
The HAMILTON-HF90 is an all-in-one solution for high flow oxygen therapy, providing caregivers with the tools and flexibility needed to tailor treatment to each patient’s unique needs. A simple solution to enhance patient comfort and enable patient mobility.
The safety-lock system secures each connector firmly in place. A simple setup with just two components:
Pulse, SpO2, Perfusion Index (
With the SpO2 option installed, you can view the following parameters in real-time during the therapy:
The device can store up to 72 hours of monitored data.
The device offers both neonatal/pediatric and adult/pediatric settings, and automatically detects the patient group based on the breathing circuit set used.
Default therapy settings can be configured for Flow, Oxygen, and Temperature to reduce the number of manual adjustments needed.
In addition, the device also detects a change of breathing circuit so therapy can continue seamlessly for the same patient.
There is no need to reset parameters unless you are starting therapy for a new patient.
Both circuit options are single limb and double walled, designed to prevent rapid air cooling and minimize the risk of condensation.
Humidity levels are adjusted automatically in response to changes in temperature, which is regulated by integrated sensors at the patient end.
These take into account any difference between room and circuit temperatures to ensure the optimal therapy temperature is maintained.
The ergonomic design and integrated holder enable you to attach the chamber to the device with one hand, while holding the breathing circuit with the other.
The direct connection between the water chamber and breathing circuit means mixed and humidified gas flows straight from one to the other without passing through the device. The only components to have contact with the heated gas are disposable, so the need for intensive cleaning is reduced.
Dual floaters ensure reliable operation, even if the surface is not level. The water level is regulated by sensors and can be monitored visually using the maximum fill level indicators on either side of the chamber. High and low water level alarms prevent both overfilling and the delivery of dry gas to the patient.
An Aerogen Solo nebulizer can be connected to the water chamber's nebulizer port and activated through the display settings.
The HAMILTON-HF90 offers you various nebulization options, including customizable timing for timed or continuous operation, and the ability to pause treatment manually for greater control and convenience.
Discover the HAMILTON-HF90 from every angle and click on the hotspots to learn more.
| Patient groups | Adult, pediatric, and neonatal patients |
|---|---|
| Monitor | 5-inch color capacitive touch screen |
| Flow rate | 2–80 l/min |
| Oxygen | 21%–100% |
| Temperature | 31°C–39°C (in 1°C steps) |
| SpO2 | SpO2 consumables for adult, pediatric, and neonatal patients available. Choose between reusable and single-use products, depending on your institutional policies. |
|---|---|
| Nebulization | Integrated nebulizer port on the humidification chamber to connect your Aerogen Solo nebulizer. Control the Aerogen Solo nebulizer through the HAMILTON-HF90. |
| Trolley | The high-quality trolley is ideally equipped for intrahospital transport, featuring space for up to three oxygen bottles and five easy-to-maneuver wheels for added stability. |
| Battery | The optional battery can run independently for up to two hours, and the battery status is shown on the main screen and the battery itself. An optional battery charger is also available. |
| Connectivity | The HAMILTON-HF90 offers a serial RS-232 interface and several protocols for connection to patient monitoring systems, patient data management systems (PDMS), and Nurse call, etc. Download Connectivity: Patient monitoring, EHR/EMR/PDMS (PDF) |
| Cleaning process | The HAMILTON-HF90 is a low-maintenance device, which can be easily cleaned with approved cleaning and disinfection wipes. |
|---|---|
| Oxygen connection | Low-pressure oxygen (LPO) connector |
The HAMILTON-HF90 is an all-in-one solution for high flow oxygen therapy, providing caregivers with the tools and flexibility needed to tailor treatment to each patient’s unique needs.
Whether in the emergency room, intermediate care, or the ICU, the HAMILTON-HF90 is designed to deliver high flow oxygen therapy whenever required during transfer and mobilization of patients within healthcare facilities.
It combines comprehensive functionality with an intuitive design to support optimal outcomes, enhance patient comfort, and enable patient mobility.
